Commercial Electric Boiler
- These boilers are designed to connect water tanks and floor heating pipes, providing central heating and domestic hot water in real-time.
- They are suitable for large areas, and capable of handling extensive heating requirements efficiently.
- The boilers are designed for high-power applications, indicating their capability to handle significant heating demands.
Compact Design
Low-noise Operation
Safe Protection
Constant Temperature
Structure：
- The boilers are floor-standing units, given their high-power output and the need to heat large spaces.
- Their design probably emphasizes functionality and capacity, with a focus on reliability and durability to meet commercial heating demands.
Usage:
- These boilers are used for providing central heating and domestic hot water in large buildings and facilities.
- They are capable of efficiently managing the heating requirements of structures with significant space, such as schools and hotels.
Suitable Application Scenarios:
- Ideal for large commercial or institutional buildings like schools, hospitals, and hotels where consistent and reliable heating is necessary.
- Also suitable for commercial squares and factories, indicating their utility in industrial applications as well.
Different Series of Commercial Electric Boiler
| Model | BL3158 | BL3200 | BL3320 | BL3415 | BL3456 |
| Power | 158kW | 200kW | 320KW | 415KW | 456KW |
| Voltage | 400V | ||||
| Frequency | 50Hz/60Hz | ||||
| Phase | 3 | ||||
| Current（A） | 3*229 | 3*319 | 3*464 | 3*601 | 3*661 |
| Wire（mm2） | ≥120 | ≥150 | ≥240 | ≥300 | ≥400 |
| Working Temp. Range | 30°C~80°C (in radiator mode) | ||||
| 30°C~60°C (in floor heating mode) | |||||
| Max. Water Temperature | 80°C | ||||
| Temperature Difference Setting Range | 5~30°C | ||||
| Antifreeze Start Temperature | <8°C | ||||
| Antifreeze Stop Temperature | ＞ 10°C | ||||
| Output Voltage of Pump | 220Vac, 0.5A | ||||
| Inlet & Outlet Connection | DN65(G2.5”) | 2*DN40(G1.5”) | 2*DN65(G2.5”) | 2*DN65(G2.5”) | 2*DN100(G4”) |
| Backwater Inlet connection | DN65(G2.5”) | 2*DN40(G1.5”) | 2*DN65(G2.5”) | 2*DN65(G2.5”) | 2*DN100(G4”) |
| Product Size（mm） | 1375*585*1420 | 1150*905*1640 | 1520*900*1656 | 1870*900*1675 | 2045*900*1675 |
| Model | BG352 | BG378 |
| Voltage | 400V | |
| Frequency | 50Hz/60Hz | |
| Phase | 3 | |
| Power | 52kW | 78kW |
| Current (A) | 3*75.4 | 3*113 |
| Wire (mm²) | ≥25 | ≥50 |
| Application | ||
| Circuit Breaker (A) | 100 | 160 |
| Working Temp. Range | 30°C~80°C (in radiator mode) | |
| 30°C~60°C (in floor heating mode) | ||
| Max. Water Temperature | 80°C | |
| Temperature Difference Setting Range | 5~30°C | |
| Antifreeze Start Temperature | <8°C | |
| Antifreeze Stop Temperature | ＞ 10°C | |
| Output Voltage of Pump | 220Vac, 0.5A | |
| Inlet & Outlet Connection | G1” | |
| Backwater Inlet connection | G1 | |
| Product Size | 490*485*960mm | |
Commercial Electric Boiler Features
